$239(tax included)
Sales unit: 1 piece
Application number: 25689834 / Model number: 25689834 / JAN code: / AS ONE / Navis product number:
| Application number | 25689834 |
|---|---|
| Model number | 25689834 |
| JAN code | |
| Sales unit | 1 bottle |
| price | $239 (tax included) |
*Additional shipping charges will apply for this product in Okinawa Prefecture, remote islands, some other areas, and mountainous regions. Please note that we may not be able to deliver to some areas. If delivery is not possible after your order is placed, Askul will contact you.
Please note the following points as this product is shipped directly.
- This product incurs additional shipping charges for Okinawa Prefecture, remote islands, some other areas, and mountainous regions. Please note that we may not be able to deliver to some areas. If delivery is not possible after your order is placed, we will contact you.
- This product may not come with an invoice issued by ASKUL. If you would like an invoice issued by ASKUL, you can print it as a PDF file from your usage history on this website after the product arrives.
- The product will not be delivered in an Askul cardboard box or bag.
- We cannot accept changes, cancellations, returns, or exchanges after an order has been placed due to customer convenience.
- If we find that we cannot deliver the product after you have placed your order, we may cancel your order.
- If we find that an item is temporarily out of stock after you place your order, we will deliver it to you as soon as it arrives in stock.
This image is a representative image. Please check the specifications for details.
In stock: Limited
Direct delivery items
Shipping costs for this item will be borne by us.
$239 (tax included)
Product details
Print product information
| Product Features | This product was released in 1982 for 108,000 yen. It's an integrated amplifier equipped with a Super Servo Integral system and a Delta Turbo power supply. It's in beautiful condition and fully functional, but the A lamp on the speaker selector switch is out.Basic Specifications:Rated Output (20Hz～20kHz): 100W + 100W (AUX → SP Out, 8Ω, both channels driven)Total Harmonic Distortion (20Hz～20kHz): 0.008% / 0.006% (AUX → SP Out, at rated output / at 1/2 output)Intermodulation Distortion (AUX → SP Out): 0.008%Power Bandwidth: 5Hz～100kHz (IHF -3dB, THD 0.2%)Damping Factor (1kHz, 8Ω): 100Frequency Response:Phono → Rec out / RIAA Deviation: 20Hz～20kHz ±0.2dBAUX → SP Out: 2Hz～100kHz +0 -3dBInput Sensitivity / Impedance:Phono MM: 2.9mV / 47kΩ, 100kΩPhono High MC: 2.9mV / 100ΩPhono MC: 180μV / 100Ω, 330ΩTuner, AUX, Tape Play: 150mV / 47kΩPhono Maximum Allowable Input (1kHz / 10kHz, 0.05%):Phono MM: 270mV / 1300mVPhono High MC: 270mV / 1300mVPhono MC: 17mV / 82mVOutput Voltage / Impedance:Tape Rec: 150mV / 2.2kΩPre Out: 1.5V / 600ΩS/N Ratio (IHF Shorted):Phono MM: 88dBPhono MC: 70dBTuner, AUX, Tape Play: 100dBTone Control (Vol -16dB):Bass: ±8dB (70Hz)Treble: ±8dB (20kHz)Loudness: +6dB (100Hz)Subsonic Filter: 15Hz, 20Hz, 6dB/octMuting: -20dBPower Supply: AC 100V, 50Hz / 60HzPower Consumption (Electrical Appliance and Material Safety Law): 160WAC Outlets: unswitched: 1 (200W), switched: 2 (total 200W)External Dimensions: Width 465 x Height 143 x Depth 392mmWeight: 15kgProduct InformationCategoryElectronics > Home Audio > Home Audio Amplifiers BrandOnkyoConditionGood | ||
|---|---|---|---|
| remarks | [Regarding returns] We cannot accept returns due to customer convenience. | ||
| Product details information |
Manufacturer site is here
Find furniture and interior items easily! Click here for Askul's general furniture homepage.
Consult us about layout, construction, and delivery dates! Click here for ASKUL office construction services.
|
||
* Disclaimer:
While we strive to display the most up-to-date product information on this site, product standards and specifications (volume, packaging, ingredients, country of origin, etc.) may change due to manufacturer circumstances. For this reason, the actual product delivered may differ from the product information on the site, so please be sure to check the product label and precautions for the delivered product before use. If you require more detailed product information, please contact the manufacturer. Also, the "set" designation in the sales unit does not guarantee that the product will be delivered in a box. Thank you for your understanding.
